MiniPlex-2S NMEA Multiplexer
Prices do not include VATOriginal price was: 271.90€.260.00€Current price is: 260.00€.
The ShipModul MiniPlex-2S NMEA Multiplexer is designed for reliable integration and management of NMEA 0183 marine navigation data.
It combines data from multiple onboard navigation instruments and enables efficient communication between connected marine electronics, making it an ideal solution for yachts, pleasure boats and professional marine applications.
Key Benefits
- NMEA 0183 data multiplexing
- Multiple marine instrument integration
- Intelligent NMEA data routing
- NMEA sentence filtering
- Reliable onboard data communication
- Suitable for navigation system upgrades and retrofits
- Compact marine installation
- Manufactured by ShipModul
10 in stock (can be backordered)
Guarantee Safe Checkout
Description
Description
ShipModul MiniPlex-2S NMEA Multiplexer
The MiniPlex-2S NMEA Multiplexer from ShipModul is a professional solution for integrating multiple NMEA 0183 marine navigation instruments into a reliable and manageable onboard data network.
Designed for marine electronics installations where several NMEA devices need to exchange information, the MiniPlex-2S collects data from connected instruments and combines the information for distribution to other navigation equipment.
NMEA 0183 Marine Data Integration
The MiniPlex-2S can be used as part of an NMEA 0183 network incorporating equipment such as:
- GPS and GNSS receivers
- AIS equipment
- Autopilots
- Gyro and heading sensors
- Depth sounders
- Speed and log instruments
- Wind instruments
- Navigation displays
- Chartplotters
- Other compatible NMEA 0183 equipment
By combining multiple NMEA data sources, the multiplexer helps simplify onboard wiring and improves the organization of navigation data.
Intelligent NMEA Data Management
The MiniPlex-2S provides intelligent handling of NMEA data rather than simply combining incoming signals.
Its routing and filtering capabilities allow installers to control how NMEA sentences are distributed between connected devices. This can be particularly useful when several instruments transmit similar information or when specific data needs to be forwarded only to selected equipment.
Ideal for Marine Electronics Upgrades
The ShipModul MiniPlex-2S can be used for new installations as well as upgrades and modifications of existing NMEA 0183 navigation networks.
Typical applications include:
- Pleasure boats
- Sailing yachts
- Motor yachts
- Commercial vessels
- Workboats
- Navigation electronics retrofits
- NMEA 0183 network expansion
- Marine instrumentation integration
Professional NMEA Integration
Correct NMEA integration depends on the interfaces, communication requirements and existing equipment installed onboard.
For installations involving multiple navigation instruments or legacy marine electronics, professional configuration can help ensure reliable data communication.
Contact our marine electronics team with details of your existing equipment and required connections, and we can assist with selecting the appropriate NMEA multiplexer, interface and integration solution for your vessel.
| MiniPlex-2S Technical specifications | |
|---|---|
| Supply voltage: | 8-35 VDC, protected against reversed polarity |
| Current consumption: | 50 mA (100 mA max. with fully loaded talker ports) |
| Host interface: | RS232, galvanically isolated |
| Inputs: | 4 x NMEA 0183/RS422, galvanically isolated In 4 can be set to SeaTalk mode |
| Input resistance: | > 800 Ohm |
| Input current: | 1.2 mA @ 2 V |
| Outputs: | 2 x NMEA 0183/RS422 |
| Max ouput current: | 20 mA @ > 2 V |
| Routing table size: | 50 sentence types |
| Priority table size: | 50 sentence types |
| Speed NMEA 0183 In 1 – 3: | 4800 – 57600 baud |
| Speed NMEA 0183 In 4/Out 1: | 4800 – 57600 baud |
| Speed NMEA 0183 Out 2: | 4800 – 115200 baud |
| Indicators: | Overflow and Data |
| Housing: | Flame retardant ABS |
| Dimensions: | 138 x 62 x 30 mm |
