Actisense PRO-MUX-2 Intelligent NMEA 0183 Multiplexer
Prices do not include VAT792.49€
PRO-MUX-2 Intelligent Type Approved NMEA 0183 Multiplexer
Eight OPTO-isolated inputs and six ISO-Drive™isolated outputs. Offering device protection and excellent flexibility, all in one product.
Introducing the Actisense® PRO-MUX-2, the intelligent, type-approved PRO range multiplexer.
The PRO-MUX-2 is rugged, with a stainless steel housing, and provides isolation on all inputs and outputs. With eight NMEA 0183 inputs, six NMEA 0183 outputs, a bi-directional serial port and an Ethernet port, the PRO-MUX-2 is a perfect solution for larger leisure vessels, commercial shipping and is a great addition for systems that require type-approved devices.
The PRO-MUX-2 is designed to suit the majority of NMEA 0183 systems, from leisure through to class vessels.
Available on backorder
Guarantee Safe Checkout
Description
Description
The Actisense PRO-MUX-2 is an advanced, commercial-grade NMEA 0183 multiplexer designed to combine, route, and filter data across complex vessel navigation networks. Equipped with 8 Opto-Isolated inputs and 6 ISO-Drive outputs, the Actisense PRO-MUX-2 consolidates multiple serial data sources—including GPS receivers, AIS transponders, heading sensors, and echo sounders—into optimized streams for chartplotters, ECDIS units, and onboard PCs.
Featuring an integrated Ethernet interface and a bi-directional serial port, the device enables high-speed data streaming over TCP/IP and UDP protocols. Its web-based configuration tool allows marine engineers to easily set up advanced sentence-based filtering, input autoswitching, custom baud rate conversions (up to 115,200 baud), and live diagnostic monitoring without installing external software.
Features
- 8 OPTO-isolated NMEA 0183 inputs
- 6 ISO-Drive NMEA 0183 outputs
- Bi-directional isolated serial port (can be used for additional NMEA 0183 input/ output)
- 0183 streaming via Ethernet
- Alarm output (N/O and N/C contacts)
- Designed for 12- and 24-Volt supply
- Isolation to battery supply
- Configurable input and output baud rates for rate conversion
- Data combining from any input to any output
- 2 independent Autoswitch virtual inputs with priority
- Advanced sentence-based filtering / routing
- Diagnostic LEDs on all inputs and outputs
- Alarm, mode and Bi-colour Status LED’s
- 2-part pluggable connector system supports both screw and screwless terminals
- DIN rail or Panel mountable
- Advanced statistics are available via a Web Browser
Benefits
- Quick and easy to install
- Configuration using standard web browser, no PC operating system compatibility issues
- Advanced features solve NMEA 0183 data routing problems
- Fully isolated with ISO-Drive technology for peace of mind
- Easy firmware updates makes the device future-proof
Use Case
Multiplexers are typically used to combine multiple instruments data output into a smaller number of outputs. As you can’t connect two talkers to one listener directly, a multiplexer allows for the data to be output through one talker connection.
An example of this could be on a commercial vessel with multiple NMEA 0183 GPS, wind, AIS and depth instruments. To get all of this data combined and sent to a display or converted via an NGX to NMEA 2000, a PRO-MUX-2 can be used.
With the PRO-MUX-2, the data can be filtered, passed or blocked and monitored, giving greater flexibility and control over all instrument data.
Tech Specs
| Power Supply | |
| Input Supply Voltage | 9 to 35 V DC |
| Input Supply Current | 220mA max @ 12V DC (all outputs @ full drive into 100 ohm loads) |
| Input Protection | Continuous reverse polarity, transient overvoltage and ESD protection |
| Power Indicator | LED, Blue – indicates unit is functioning correctly |
| Input Supply Connector | Pluggable 2-way screw terminal, 5.08mm pitch (12 to 30 AWG) |
| NMEA 0183 Port – Listener & Talker | |
| Number of Listener / Input Ports | 8 isolated NMEA 0183 Listeners |
| Number of Talker / Output Ports | 6 isolated NMEA 0183 Talkers |
| Compatibility | Fully NMEA 0183, RS422 & RS232 compatible. RS485 Listener compatible |
| Speed / baud rate | 4800 to 38400 bps |
| Talker Output Voltage Drive | >= 2.2V (differential) into 100 ohm |
| Talker Output Current Drive | 20 mA maximum per output |
| Talker Output Protection | Short circuit and ESD |
| Talker Data Indicator | LED, Orange (Flashes at data rate) |
| Listener Input Voltage Tolerance | -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second) |
| Listener Input Protection | Current limited, overdrive protection to 40 VDC and ESD protection |
| Listener Data Indicator | LED, Green (Flashes to indicate valid input) |
| Connectors | Pluggable 2/3-way screw terminals, 5.08mm pitch (12 to 30 AWG) |
| Serial Port | |
| Compatibility | RS422 & RS232 compatible. RS485 Listener compatible |
| Speed / baud rate | 4800 to 115200 bps |
| Output Voltage Drive | >= 2.1V (differential) into 100 ohm |
| Output Current Drive | 20 mA max. |
| Output Protection | Short circuit and ESD |
| Input Voltage Tolerance | -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second) |
| Input Protection | Current limited, overdrive protection to 40 VDC and ESD protection |
| Data Indicators | LED’s: Green = Receive, Orange = Transmit |
| Connectors | Pluggable 3-way screw terminals, 5.08mm pitch (12 to 30 AWG) |
| Ethernet Port | |
| Host Interface | 10/100BaseT, automatic polarity detection |
| Supported Protocols | TCP/IP for configuration and firmware updating |
| TCP/IP and UDP for NMEA 0183 comms | |
| Indicators | Green = Link/Activity, Yellow = 100 Mbps |
| Connector | RJ45 |
| Isolation | |
| NMEA 0183 Listener | OPTO-Isolated, Hi-Pot tested to 1000V |
| NMEA 0183 Talker | Uses IsoDrive™, Hi-Pot tested to 1000V |
| Serial Port | Uses IsoDrive™, Hi-Pot tested to 1000V |
| Alarm Relay | Hi-Pot tested to 1000V |
| Ethernet Port | 2kV for 60s |
| Mode Inputs | |
| Input Voltage Range | 0 to 35V DC |
| Protection | Transient overvoltage and ESD protection |
| Connectors | Pluggable 2-way screw terminals, 5.08mm pitch (12 to 30 AWG) |
| Alarm Output | |
| Contacts | Common, Normally Open and Normally Closed |
| Alarm Indicator | LED, Red indicates a valid alarm condition |
| Contact Ratings | 35VAC / 50VDC |
| Connectors | Pluggable 3-way screw terminals, 5.08mm pitch (12 to 30 AWG) |
| Mechanical | |
| Housing Material | 316 Stainless Steel |
| Dimensions | 210mm (W) x 128mm (H) x 27mm (D) |
| Weight | 540g |
| Mounting | Bulkhead mount or DIN rail mount (DIN kit 1) |
| Approvals and Certifications | |
| EMC | IEC 60945:2002-08, DNVGL-CG-0339:2019 & IACS UR E10 Rev7 |
| Compass Safe Distance | 175mm |
| Type Approval Certificate | RINA |
| Operating Temperature | -25 to +70°C |
| Storage Temperature | -40 to +85°C |
| Relative Humidity (RH) | 95% @ 55°C |
| Environmental Protection | IP40 |
| Guarantee | 5 Years |
| Guarantee | 5 years
|
Geek Mode
- Ethernet port – for configuration, diagnostics and data streaming
- 8 OPTO-Isolated NMEA 0183 inputs
- 6 ISO-Drive NMEA 0183 outputs
- Advanced Data Filtering/Routing
- Configurable Input and output baud rates
- Serial port – for configuration, diagnostics or as an additional NMEA 0183 input/output.
- Free firmware updates make the device future-proof
- Alarm output relay (N/O and N/C contacts available)
- Mode inputs to provide manual selection of operational mode
- Diagnostic LEDs on all inputs and outputs
- Alarm status LED
- Mode LED
- Bi-colour status LED
- DIN rail or Panel mountable
- Pluggable connectors for quick and easy installation
