A2K-GC
Prices do not include VAT32.72€
A2K-GC Lite Gender Changer Cables
Use between two cable connectors of the same type and gender of connector on an NMEA 2000® backbone.
Manufactured using Actisense designed connectors with 0.25m UL certified cable, the gender changers offer easy and secure connections.
The gender changers are available in male and female versions.
The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.
Available on backorder
Guarantee Safe Checkout
Description
Description
Ordering Informations
To order the Lite Gender Changer Cables, please use the following product codes:
- A2K-GCF-0M25 Lite gender changer (female to female), 0.25 metre UL certified cable
- A2K-GCM-0M25 Lite (male to male) 0.25 metre UL certified cable
Tech Specs
| Electrical | |
| Rated Current | 3A |
| Rated Voltage | 60VDC |
| Mechanical | |
| Male Contact | Brass, gold plated |
| Female Contact | Phosphor bronze, gold plated |
| Contact Carrier | PA66 (30% Glass filled), black |
| Contact Polarisation | Standard M12 -“A”- polarisation |
| Mating Thread | M12 |
| Screw Cap | Brass, nickel plated |
| O-Ring Seal | Rubber, black |
| Housing | PVC, black |
| Power Pair | 22 AWG (19 strand tinned copper) |
| Data Pair | 24 AWG (19 strand tinned copper) |
| Drain | 22 AWG (19 strand tinned copper) |
| Braid | 37 AWG (tinned copper) |
| Jacket Material | 0.8mm Nom. PVC, black |
| Jacket Outer Diameter | 6.85mm ±0.254mm |
| Weight | 50g |
| Length | 0.25m |
| Approvals and Certifications | |
| Protection | IP67 (when mated) |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| NMEA 2000 Approved | |
| RoHS Compliant | |
| UL Certified (E137250), (UL1277) | |
